RATINGS / PERFORMANCE FA-97A
Input Signal External Sync	SYNC 0.6 Vp-p ±6 dB 75 Ω BNC CN 1 ch (BB / PS Signal)
Input Signal Audio	-60 dB to +4 dB (variable) / -20 dB (fixed) XLR CN 2 ch (600 Ω balanced)
Input Signal Video Trunk	Serial Digital 75 Ω BNC 1 ch (Option))
Output Signal 3G-SDI/HD-SDI	Serial Digital 75 Ω BNC 1 ch
Output Signal Analog Video	R, G, B D-Sub CN 1 ch (for System Expander)
Output Signal Q-TV	VBS signal 1 ch
Output Signal HD Q-TV*	Serial Digital 75 Ω BNC 1 ch (Option)
Output Signal Monitor Video (1.5G)	VF / RET / MON (MENU Selection) Serial Digital 75 Ω BNC 1 ch or VF / RET / MON / HD Q-TV (MENU Selection) Serial Digital 75 Ω BNC 1 ch (factory option) *Optional HD Q-TV (Trunk) module should be installed in CCU
Output Signal Intercom	0 dBs 4 ch (ENG / PROD / PGM1 / PGM2) XLR Type or 110 Type CN
