POIE-Series
RATINGS


The POIE-8000C Colour Powdered/Granulated Medicine Inspection Device combines the colour processing technology developed for tablet inspection equipment with technology for screening powdered and granulated medicines for impurities, thereby boosting the precision with which coloured foreign matter can be detected. This new device also allows for certain colours to be specified for the detection of foreign matter that colour. The device also comes equipped with a “linear feature extraction processing function”, which facilitates the high-precision detection of fine fibers and hairs.With this new equipment wcomes a marked increase in processing capacity thanks to the wide inspection conveyor belt that provides a stable, constant supply of sample material and the five-speed conveyor belt action (top speed is approximately 18m/minute). In addition, the exclusion mechanism employs a reliable rotary nozzle system. This ensures that accurate pinpoint suction is provided only around the foreign substance, thereby boosting the recovery ratio of quality product.

  • Max. Output: 200kg/h
  • 5000 Pixel RGB Colour Line Sensor / 20 μm resolution
  • Detect fiber/hair/foreign Material
  • Colour Processing
  • Fiber Lighting for uniform and high intensity Illumination
  • Stable and constant Feeding with 2nd Transfer Unit
  • Spot Vacuum with Rotary Nozzle System
  • Correct Rejection Control
  • Easy Operation with Touch Panel
  • Detection Image Memory
You want further information?

Feel free to contact us.
Service-Hotline: +49 (0) 2131 1230
E-Mail: industrial@ikegami.de
Contact Form

up

RATINGS / PERFORMANCE POIE-Series
Applicable Particle Powder, Fine Granule, Granule etc., Coloured
Inspection Throughput 20 to 100 kg / hour
Inspection Objects Black or coloured foreign particle of over 40 to 60 μm (diameter)
Black or coloured fiber and hair of over 30 μm (diameter) x 3 mm
(Inspection accuracy depends on inspection throughput and object)
Transport Belt / Speed 1 row  / Approx. 9 to 18m / minute (5 steps selectable)
Transported Particle Thickness Step Gain :-6, -3, 0, +3, +6, +9, +12 dB
Transport Section Inspection Area Approx. 392 mm in width
Transported Particle Thickness Approx. 0.3 to 0.7mm (1 layer)
Limit Of Resolution 5,000 pixel RGB CCD line sensor camera x 4 units – 20 μm
Lighting System / Source / Position Fiber guide / Halogen lamp x 12 / 2 spots at top, 1 spot at bottom
Lamp Sytem DC lighting system (lighting level variable at 16 steps)
Lighting Control Manual, Auto control selectable 
Expected Lamp Life 1,000 to 1,500 hours
Power Supply Three phase 200 V ± 10%, 50 / 60 Hz
Power Consumption 5 k VA or less
Power Connection Terminal fixed with 6 mm-screw
Pressured Air Pressure 0.5 M pa or more
Air Consumption 0.7 NL / minute or less (clean dry air)
Air Coupling Socket Size Quick-connect air coupler socket 20 SH
Air Coupling Socket Size Quick-connect air coupler socket 20 SH
Control Unit / Main Unit W 570 x H 1850 x D 710 mm / W 1708 x H 2050 x D 1149 mm
Air-Vacuuming Unit W 750 x H 1333 x D 532 mm
Weight Control Unit / Main Unit Approx. 150kg (330 lbs) / Approx. 1,000 kg (2,203 lbs)
Environment Condition Temperature 15°C to 20°C (59 -77 degree F)
Vacuumed Air Exhaust Negative Pressure 4 K pa or more
Exhaust Air Emission 10 cubic meter / minute
